ASME SA789 Duplex Stainless Steel Tubes S31803 1.4462 Condenser Tube 1/4 3/8 1/2 Inch
Product Details:
| Place of Origin: | China |
| Brand Name: | KORER |
| Certification: | ISO 9001 And Manufacture License Of Pressure Tube |
| Model Number: | OD: 6mm-101.6mm, WT:0.3mm – 3.5mm |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Metric Tons Per Size |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Boxes With Angle Steel Frame Or Seaworthy Bundle |
| Delivery Time: | 15Days – 45Days Or Depends on the quantity |
| Payment Terms: | T/T L/C |
| Supply Ability: | 10000 Metric Tons Per Year |
|
Detail Information |
|||
| Product Name: | Duplex Stainless Steel Tubes | Pipe Type: | Longitude Welding |
|---|---|---|---|
| OD: | 6mm-101.6mm | Application Filed: | Condenser Tube |
| Standard: | ASME SA789 | Delivery Condition: | Bright Annealing |
| High Light: | duplex stainless steel pipe,duplex stainless steel tubing |
||
Product Description
Welded Duplex Stainless Steel Tubes With ASME SA789, S31803 For Condenser,1.4462
Quick detail:
|
Name |
Duplex Stainless Steel Tubes |
Pipe Type |
Longitude Welding |
|
Standard |
ASME SA789 |
Delivery Condition |
Bright Annealing |
|
Brand Name |
KORER |
Application Filed |
Condenser Tube |
Description:
|
America |
Germany |
Japan |
||
|
AISI |
UNS |
EN/DIN |
JIS |
|
|
304 |
S30400 |
1.4301 |
X5CrNi18-10 |
SUS304 |
|
304L |
S30403 |
1.4306 |
X2CrNi19-11 |
SUS304L |
|
310S |
S31008 |
∕ |
∕ |
SUS310S |
|
321 |
S32100 |
1.4541 |
X6CrNiTi18-10 |
SUS321 |
|
316 |
S31600 |
1.4401 |
X5CrNiMo17-12-2 |
SUS316 |
|
316L |
S31603 |
1.4404 |
X2CrNiMo17-12-2 |
SUS316L |
|
317 |
S31700 |
1.4436 |
X5CrNiMo17-13-3 |
SUS317 |
|
317L |
S31703 |
1.4438 |
X2CrNiMo18-15-4 |
SUS317L |
|
2205 |
S31803 |
1.4462 |
X2CrNiMoN 22-5-3 |
∕ |
|
430 |
S43000 |
1.4016 |
X6Cr17 |
SUS430 |
|
409 |
S40900 |
1.4512 |
X2CrTi12 |
SUS409 |
|
439 |
S43035 |
∕ |
X3CrTi17 |
SUS439 |
Standards:
|
A789 Specification for seamless and welded Ferritic/Austenitic stainless steel tubing for General Service |
||
|
Item |
Contents |
Requirements |
|
1 |
Materail |
S31803, S32205, S32304, S32507 Etc |
|
2 |
Welding Method |
Seamless Or Automatic Welding Process With No Addition Of Filler Metal During The Welding Process |
|
3 |
Chemical Composition |
Acc.to A789, A480, A1016 |
|
4 |
Heat Treatment |
Annealing Acc.to Table 3 In ASTM A789 |
|
5 |
Straightness |
Depends on Requirements of Buyer |
|
6 |
Tolerance |
OD / WT / Length :Acc.to Table 5 |
|
7 |
Mechanical Property |
Tension Test, Flattening Test, Expansion Test, Flange Test(For Weld Tube), Reverse-Bend Test, Hydrostatic or Other Nondestructive Test |
Applications:
The Pipes are Used For Boiler, Superheater, Heat-exchanger,Pressure Vessel and Condenser In Thermal Power Station, Nuclear Power Staition, Paper Sugar / Pulp Fertilizers, Petrochemical Industry Etc.
Specifications:
|
1)Duplex Stainless Steel Tubes |
|
2)Standard: ASME SA789 |
|
3)Material Grade: S31803, 1.4462 |
|
4)Outer Diameter:6mm-101.6mm |
|
5)Wall Thickness:0.3mm – 3.5mm |
|
6)Length:Depends on Customers’ Request |
|
7)Tolerance:According to ASME SA789 and A1016 |
|
8)Leakage Test:ET Or Hydraulic Test Or Air Pressure Test Under Water |
|
9)Main process:Welding, Annealing |
|
10)Certificate:ISO 9001:2008, Manufacture License Of Pressure Pipe |
|
11)Marking:Brand, Standard, Grade, Size, Length and Heat No. Or Depends On Customer. |
|
12)Packing:Bundles With Plastic Bags, Wooden Box With Angle Steel Frame Or others |
|
13)Payment Terms:T/T, L/C at sight |
|
14)Delivery Time:Generally 15Days – 45Days Or Depends on the quantity and Customers’ Request |
|
15)Capacity:1000 Tons Per Month |
Competitive Advantage:
I. Supply Best Prices With Good Quality Of The Materials.
II. Prompt Delivery Time Based On Sales Contract.
III. We Have Advanced Ndt Equipments For The Tests Such As Eddy Current Test, Ultrasonic Test,
Hydraulic Test And So On.
IV. We Have Complete After-Sale Service To Deal With The Problems In Time.
V. Wooden Case Package Which Is Strong And Suitable For Sea Transport And Which Is Our Main Method To Protect The Tubes.Also We Will Depends On The Sizes Of The Tubes To Select More Ecomony Packing Method By Bundle.
